Vector Gateway Interface for Java

Extend DuckDB with functions written in Java — backed by Apache Arrow, callable straight from SQL.

farm.query:vgi implements the Vector Gateway Interface (VGI) for Java: you write a small worker exposing typed functions, and DuckDB calls them as if they were native. Data moves as Apache Arrow record batches, so it stays columnar across the boundary — no row-by-row marshalling.

Install

implementation("farm.query:vgi:0.26.1")

Requires JDK 21+ (JDK 22+ unlocks the shared-memory transport). Two JVM flags and the -parameters compiler flag are part of the contract — see Running a worker.

A scalar function is a class with one method:

public final class ScalarExample extends ScalarFn {
  @Override public String name() { return "upper_case"; }

  // @Vector marks a per-row input column; the last unannotated vector is the
  // framework-allocated output.
  public void compute(@Vector VarCharVector value, VarCharVector result) {
      result.allocateNew();
      for (int i = 0; i < value.getValueCount(); i++) {
          if (value.isNull(i)) { result.setNull(i); continue; }
          byte[] up = new String(value.get(i), UTF_8).toUpperCase(Locale.ROOT).getBytes(UTF_8);
          result.setSafe(i, up, 0, up.length);
      }
  }

  public static void main(String[] args) {
      Worker.builder()
            .catalogName("demo")
            .registerScalar(new ScalarExample())
            .runFromArgs(args);
  }
}

ATTACH 'demo' (TYPE vgi, LOCATION 'launch:/abs/path/bin/demo');
SELECT demo.upper_case('hello');   -- HELLO

Start here

Tutorial Zero to a scalar and a table function callable from DuckDB, in about 20 minutes.

Concepts What VGI is, the worker model, and the Arrow data path — shared across every SDK.

API reference The whole artifact — function shapes, worker, catalogs, client — generated from the sources.

Function lifecycle When bind, init, process, combine and finalize each run, and how they map to DuckDB.

Three things to know up front

The method signature is the SQL signature. @Vector, @Const and @Setting on compute’s parameters generate the spec, the bind-time validation and the dispatch. There is no separate declaration to keep in sync — and no schema boilerplate.
How you run it matters as much as what you write. A cold JVM costs seconds, so launch: (one reused worker) rather than a bare path is the difference between usable and not.
It can skip the pipe entirely. On JDK 22+, large Arrow batches pass through a POSIX shared-memory segment both processes map, negotiated at the transport layer with no code change in your worker.

Coming from another SDK? The protocol is identical and a Java worker is wire-compatible with a Python, Go, Rust or TypeScript one — the same DuckDB extension drives all of them.

Reference

Package overview Orientation for the artifact, plus the map of every reference page.

Argument serialization The Arrow schema every SDK produces for a function signature — the shared wire format.
